$190.00

Estimated Lead Time: 4-5 Weeks

The XTR Slide Out Kit allows you to mount a piece of Xtrusion on the inside of your bed rack, on either the side brace or top brace, providing you a slide out for your gear. These are used to mount accessories on the inside of your bed rack. Select your bed rack length below.

This concept uses linear bearings to create an inexpensive slide out mechanism for easy access to things such as Rotopax, Shovels, Propane tanks, etc.

What's Included:

  • (1) Slide bar to the length to match your bed rack.
  • (4-8) Linear Slide Bearings w/ Hardware - quantity depends on length of the slide.
  • (1) End Cap.
  • (1) Locking lever mechanism to go on a linear slide.

NOTES:

The full slide out is intended to be used on an XTR1 style rack (without a center upright). The center upright can interfere with proper operation of a full length slide out, so it is recommended to use a half length slide out for an XTR3 series rack.

When selecting a half length slide out, choose the full length of your rack. The slide length will be based on an XTR3 rack. For example, a 60" rack will include a 28.5" slide bar.





Slide Bar Length by rack length:

Rack Length

Slide Type

Slide Bar Length

Slide Type

Slide Bar Length

46 FULL 45.7 HALF 21.5
48 FULL 47.7 HALF 22.5
50 FULL 49.7 HALF 23.5
51 FULL 50.7 HALF 24
52 FULL 51.7 HALF 24.5
53 FULL 52.7 HALF 25
54 FULL 53.7 HALF 25.5
56 FULL 55.7 HALF 26.5
58 FULL 57.7 HALF 27.5
60 FULL 59.7 HALF 28.5
61 FULL 60.7 HALF 29
62 FULL 61.7 HALF 29.5
66 FULL 65.7 HALF 31.5
71 FULL 70.7 HALF 34
72 FULL 71.7 HALF 34.5
74.4 FULL 74.1 HALF 35.7
75 FULL 74.7 HALF 36
78 FULL 77.7 HALF 37.5
84 FULL 83.7 HALF 40.5
